AT A GLANCE
- FRAME: AL-6061 Ultralight, integrated internal battery and internal cables
- SUSPENSION: Suntour NEX E-25 HLO, 60mm, 30mm stanchions, tapered steerer, hydraulic lockout
- COMPONENTS: Bosch Active Line Plus Motor, 500Wh PowerTube battery, 9sp Microshift Advent, Tektro hydraulic brakes
- WHEELS: Formula alloy cassette hubs with Alex double wall alloy rims
WHAT'S NEW
- Microshift clutch-equipped 1x9sp
- Tektro brakes
- More durable 'E-bike' drivetrain parts
KEY FEATURES
- Bosch's Active Line Plus motor gives pedal-assist to 32kph for NZ or 25kph for AU
- A long range, fully internal 500Wh battery will extend your commutes or rambles on the bike path or rail trail further
- Fully equipped with e-bike powered lights, rear rack and full fenders for any weather or light conditions
- Adjustable rise stem for a perfectly tuned handlebar height
- Selle Royal saddle has Royal Gel inserts for the ultimate in comfortable riding
Specifications
Specifications
| Grips | Ergonomic comfort |
| Handlebar | Alloy riser bar, 15deg rear sweep |
| Headset | Integrated Threadless 1/8th-1.5" tapered |
| Pedals | VP retro with alloy body and rubber gripper |
| Rear Hub | Formula Alloy Centrelock Cassette 32H |
| Saddle | Selle Royal Lookin comfort with RoyalGel padding |
| Seatpost | Alloy Micro Adjust 31.6mm |
| Stem | Alloy Ahead Adjustable rise |
| Brake Levers | Tektro M275 Hydraulic |
| Brakes | Tektro M275 Hydraulic Disc, 180 front/160 rear Centrelock Rotors |
| Cassette | Microshift E-cassette, 11-46T, 9sp |
| Chain | KMC X9 |
| Chainring | 38T |
| Crankset | Prowheel Alloy, 38T |
| Rear Derailleur | Microshift Advent 9sp with Clutch |
| Shifters | Microshift Advent 9sp Single-Click E-bike Trail Pro trigger |
| Battery | Bosch Powertube 500Wh Internal |
| Display | Bosch Intuvia |
| Drive Unit | Bosch Gen 3 Active Line Plus, 50Nm, 250W, 32kph for NZ, 25kph for AU |
| Fork | Suntour NEX E-25 HLO, 60mm, 30mm stanchions, tapered steerer, hydraulic lockout |
| Frame | AL-6061 Alloy with Ultra Light butted tubing, fully-integrated battery and internal cables |
| Extras | Full cover fenders, integrated rear carrier rack, rear mounted kickstand and e-bike battery powered lights. |
| Rims | Alex TD26 Double-wall Alloy 32H |
| Spokes | Stainless Steel with Brass Nipples |
| Tyres | Kenda Small Block 8 29 x 1.75 with K Shield, reflective logos & AV tube |
