KEY FEATURES
- Patron eRIDE Carbon/Alloy Frame
- FOX 38 Perf. Elite 160mm Fork
- FOX Nude T eRIDE EVOL, 160mm, TwinLoc
- Shimano XT 12 Speed
- Bosch CX, 750Wh PowerTube / SmartSystem
- Shimano XT 4 Piston Disc Brakes
- FOX Dropper Post / Syncros Parts
Specifications
Specifications
| Grips | Syncros Endurance lock-on grips |
| Handlebar | Syncros Hixon 1.5 / Alloy 7050D.B. 12mm rise / 9 deg / 760mm |
| Headset | Acros / 1.8" ZS66 OD74 / integr. Cable |
| Remote System | SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 modes |
| Saddle | Syncros Savona 1.5 V-Concept |
| Seatpost | FOX Transfer Dropper Post 31.6mm / S size 125mm / M size 150mm / L size 175mm |
| Stem | Syncros AM1.5 / 7050 Alloy 31.8mm / 4 deg / 1 1/8" |
| Brakes | Shimano XT / BR-M8120 4 Piston |
| Brakes Rotor | Front: RT-MT800 CL 203mm / Rear: RT-EM800 CL 203mm |
| Cassette | Shimano CS-M8100 / 10-51 T |
| Chain | Shimano CN-M8100 |
| Chainguide | e*thirteen / e*spec Slider |
| Chainring | FSA W0138+WB499 / 34T / Steel |
| Crankset | FSA CK-745 165mm / 34T |
| Rear Derailleur | Shimano XT / 12 Speed |
| Shifters | Shimano SL-M8100 |
| Battery | PowerTube 750Wh |
| Display | Bosch LED Remote & Kiox 300 |
| Drive Unit | Bosch Performance CX |
| E Motor Charger | 4A Charger |
| Lights | Syncros integrated rear fender light Front Light Cable pre-installed |
| Fork | FOX 38 Perf. Elite Air / eMTB+ / FIT4 3-Modes with low Speed adj. / QR Axle 15x110mm axle 44mm offset / tapered steerer / Reb. Adj. / Lockout / 160mm travel |
| Frame | Carbon Main Frame / Alloy SST-CST-Link Virtual 4 link kinematic VLK 29x2.6 / Boost 148x12mm UDH 160mm travel / Bosch Gen4 / Integr. removable Battery 1.8" Headtube, Central Kickstand Mount Integr. Cable |
| Frame Material | Carbon |
| Front Travel | 160mm |
| Rear Travel | 160mm |
| Shock | FOX NUDE T eRIDE EVOL / Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend custom large air volume / DPS / Reb. Adj. Travel 160-115-Lockout / 205X60mm |
| Approx. Weight | 24.3kg (with tubes) |
| Extras | Syncros Fork Fender |
| Front Hub | Formula CL-811 / 15x110mm |
| Front Tyre | Maxxis Dissector 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra |
| Rear Hub | Formula ECT-1481 / Boost 148x12mm |
| Rear Tyre | Maxxis Dissector 29x2.6" 120TPI Foldable Bead EXO+ / TR Tubeless ready 3C Maxx Terra |
| Rims | Syncros MD30 / 32H / 30mm / Pin Joint Tubeless ready |
| Spokes | Stainless Black |
